Handheld Precious Metal Analyzer Terra990
Terra990 handheld precious metal analyzer, based on advanced ceramic packaged microfocus X-ray tube and high-performance semiconductor detector, combined with advanced software algorithm, can quickly, accurately and non-destructively test gold, silver, platinum and other precious metals concentration in jewelry, to fast indentify the purity of jewelry, investment gold and various precious metal materials.
+86519-83550835
NEED A SUGGESTION FOR YOUR APPLICATION? EMAIL US REQUEST FOR QUOTATION
Introduction

Terra990 Handheld Precious Metal Analyzer

---- Fast Indentifying the Purity You Care


Terra990 handheld precious metal analyzer, based on advanced ceramic packaged microfocus X-ray tube and high-performance semiconductor detector, combined with advanced software algorithm, can quickly, accurately and non-destructively test gold, silver, platinum and other precious metals concentration in jewelry, to fast indentify the purity of jewelry, investment gold and various precious metal materials.



Terra990 is Ideal for the Following Fields


Precious Metals Recycling

Precise analysis and identification of purity, concentration of recycled or recovered precious metals


Jewelry dealer and makers

Procurement and identification of precious metal materials for jewelry makers

Used for authenticity identification, purity analysis or gold and silver, K value testing of gold jewelry


Pawnshop

Gold authenticity identification, purity testing of precious gold and silver jewelry and investment gold.


Quality inspection agency

For the identification of the purity of precious metals, gold and silver, etc.


Industrial precious metal catalyst

For gold refining industry, monitoring of gold concentration in activated carbon

Testing precious metals such as platinum (Pt), rhodium (Rh), and palladium (Pb) in the recovery of automobile three-way catalysts

Testing recycled precious metal catalysts for chemical industry, including platinum (Pt), palladium (Pb), ruthenium (Ru), rhodium (Rh), iridium (Ir)



Advantage
Fast and Accurate
Perform fast, accurate, and reliable analysis of precious metals, with analysis results displayed in seconds
Intuitive Karat Display
Large-size high-definition touch screen, graphical interface, and intuitive test results with Karat value display
Safe and Non-destructive
Non-sestructive to gold and jewelry testing, automatic radiation protection device is installed to protect the safety of operators
Simple and Lightweight
no need for much training, easy to operate. Compact design for easy portability to anywhere and anytime to test precious metal.
Application
Specification

ExcitationHigh performance Ag target tube,50kV

DetectorHigh performance Si-Pin detector /Optimized SDD detector
FilterMulti position automatic filter changer
Window Kapton with anti-puncture window design optional
Collimator5mm collimator
Battery7.2V Li-ion battery,6800mAh
DisplayCapacitive touch color display
Data storage100000+data storage
Data transferWiFi、USB
Radiation safetySafety guard device, tube shutoff while no sample , Password-protected user security
Camera(optional)Integrated CCD camera with autofocus lens for positioning and recording measuring point positions
Elements Au,Ag,Pt,Pd,Rh,Ru,Ir,Zn,Cu,Ni,Co,Fe and more can be added if required
Environment Temp-10°C~50°C Humidity 0%~80%
WeightApprox. 1.5kg (3.3lbs) including battery
DimensionsL x W x H: 220mm*91mm*276mm
Software languageEnglish and other languages
